Snowflake's Snowpipe streaming capabilities are designed for rowsets with variable arrival frequency. It focuses on lower latency and cost for smaller data sets. This helps data workers stream rows into Snowflake without requiring files with a more attractive cost/latency profile.

Here are some of the use cases that can benefit from Snowpipe streaming:

In our demo, we will use real-time commercial flight data over the San Francisco Bay Area from the Opensky Network to illustrate the solution using Snowflake's Snowpipe streaming and MSK (Amazon Managed Streaming for Apache Kafka).

The architecture diagram below shows the deployment. An MSK cluster and a Linux EC2 instance (jumphost) will be provisioned in private subnets of an AWS VPC. The Linux jumphost will host the Kafka producer and Snowpipe streaming via Kafka Connect.

The Kafka producer calls the data sources' REST API and receives time-series data in JSON format. This data is then ingested into the Kafka cluster before being picked up by the Kafka connector and delivered to a Snowflake table. The data in Snowflake table can be visualized in real-time with AMG (Amazon Managed Grafana) and Streamlit The historical data can also be analyzed by BI tools like Amazon Quicksight. Please note that in the demo, we are not demonstrating the visualization aspect. We will have a future Quickstart demo that focuses on visualization.

Architecture diagram for the Demo

Data visualization

Prerequisites

What You'll Need Before the Lab

To participate in the virtual hands-on lab, attendees need the following resources.

What You'll Learn

What You'll Build

1. Create an MSK cluster and an EC2 instance

The MSK cluster is created in a VPC managed by Amazon. We will deploy our Kafka clients in our own VPC and use security groups to ensure the communications between the MSK cluster and clients are secure.

First, click here to launch a provisioned MSK cluster. Note the default AWS region is us-west-2 (Oregon), feel free to select a region you prefer to deploy the environment.

Click Next at the Create stack page. Set the Stack name or modify the default value to customize it to your identity. Leave the default Kafka version as is. For Subnet1 and Subnet2, in the drop-down menu, pick two different subnets respectively, they can be either public or private subnets depending on the network layout of your VPC. Please note that if you plan to use Amazon MSK Connect later, you should choose private subnets here. For MSKSecurityGroupId, we recommend using the default security group in your VPC, if you do not have the default security group, create one on your own before moving forward. Leave TLSMutualAuthentication as false and the jumphost instance type and AMI id as default before clicking Next.

See below sample screen capture for reference.

Leave everything as default in the Configure stack options page and click Next. In the Review page, click Submit.

In about 10-30 minutes depending on your AWS region, the Cloudformation template provisions an MSK cluster with two brokers. It will also provision a Linux EC2 instance in the subnet you selected. We will then use it to run the Kafka connector with Snowpipe streaming SDK and the producer.

2. Configure the Linux session for timeout and default shell

In this step we need to connect to the EC2 instance in order to interact with the MSK cluster.

Go to the AWS Systems Manager console in the same region where you setup the MSK cluster, Click Session Manager on the left pane.

Next, we will set the preferred shell as bash.

Click the Preferences tab.

Click the Edit button.

Go to General preferences section, type in 60 minutes for idle session timeout value.

Further scroll down to Linux shell profile section, and type in /bin/bash before clicking Save button.

3. Connect to the Linux EC2 instance console

Now go back to the Session tab and click the Start session button.

Now you should see the EC2 instance created by the Cloudformation template under Target instances. Its name should be -jumphost, select it and click Start session.

4. Create a key-pair to be used for authenticating with Snowflake

Create a key pair in AWS Session Manager console by executing the following commands. You will be prompted to give an encryption password, remember this phrase, you will need it later.

cd $HOME
openssl genrsa 2048 | openssl pkcs8 -topk8 -inform PEM -out rsa_key.p8

See below example screenshot:

Next we will create a public key by running following commands. You will be prompted to type in the phrase you used in above step.

openssl rsa -in rsa_key.p8 -pubout -out rsa_key.pub

see below example screenshot:

Next we will print out the public key string in a correct format that we can use for Snowflake.

grep -v KEY rsa_key.pub | tr -d '\n' | awk '{print $1}' > pub.Key
cat pub.Key

see below example screenshot:

5. Install the Kafka connector for Snowpipe streaming

Run the following command to install the Kafka connector and Snowpipe streaming SDK

passwd=changeit  # Use the default password for the Java keystore, you should chang it after finishing the lab
directory=/home/ssm-user/snowpipe-streaming # Installation directory

cd $HOME
mkdir -p $directory
cd $directory
pwd=`pwd`
sudo yum clean all
sudo yum -y install openssl vim-common java-1.8.0-openjdk-devel.x86_64 gzip tar jq python3-pip
wget https://archive.apache.org/dist/kafka/2.8.1/kafka_2.12-2.8.1.tgz
tar xvfz kafka_2.12-2.8.1.tgz -C $pwd
wget https://github.com/aws/aws-msk-iam-auth/releases/download/v1.1.1/aws-msk-iam-auth-1.1.1-all.jar -O $pwd/kafka_2.12-2.8.1/libs/aws-msk-iam-auth-1.1.1-all.jar
rm -rf $pwd/kafka_2.12-2.8.1.tgz
cd /tmp && cp /usr/lib/jvm/java-openjdk/jre/lib/security/cacerts kafka.client.truststore.jks
cd /tmp && keytool -genkey -keystore kafka.client.keystore.jks -validity 300 -storepass $passwd -keypass $passwd -dname "CN=snowflake.com" -alias snowflake -storetype pkcs12

#Snowflake kafka connector
wget https://repo1.maven.org/maven2/com/snowflake/snowflake-kafka-connector/2.0.0/snowflake-kafka-connector-2.0.0.jar -O $pwd/kafka_2.12-2.8.1/libs/snowflake-kafka-connector-2.0.0.jar

#Snowpipe streaming SDK
wget https://repo1.maven.org/maven2/net/snowflake/snowflake-ingest-sdk/2.0.2/snowflake-ingest-sdk-2.0.2.jar -O $pwd/kafka_2.12-2.8.1/libs/snowflake-ingest-sdk-2.0.2.jar
wget https://repo1.maven.org/maven2/net/snowflake/snowflake-jdbc/3.13.15/snowflake-jdbc-3.13.15.jar -O $pwd/kafka_2.12-2.8.1/libs/snowflake-jdbc-3.13.15.jar
wget https://repo1.maven.org/maven2/org/bouncycastle/bc-fips/1.0.1/bc-fips-1.0.1.jar -O $pwd/kafka_2.12-2.8.1/libs/bc-fips-1.0.1.jar
wget https://repo1.maven.org/maven2/org/bouncycastle/bcpkix-fips/1.0.3/bcpkix-fips-1.0.3.jar -O $pwd/kafka_2.12-2.8.1/libs/bcpkix-fips-1.0.3.jar

6. Retrieve the broker string from the MSK cluster.

Go to the MSK console and click the newly created MSK cluster, it should have a substring MSKCluster in its name.

Click View client information

We are going to use TLS authentication between the client and brokers. Copy down the broker string under Private endpoint for TLS authentication type.

Now switch back to the Session Manager window and execute the following command by replacing with the copied values.

export BS=<broker string>

Now run the following command to add BS as an environment variable so it is recognized across the Linux sessions.

echo "export BS=$BS" >> ~/.bashrc

See the following example screen capture.

7. Create a configuration file connect-standalone.properties for the Kafka connector

Run the following commands to generate a configuration file connect-standalone.properties in directory /home/ssm-user/snowpipe-streaming/scripts for the client to authenticate with the Kafka cluster.

dir=/home/ssm-user/snowpipe-streaming/scripts
mkdir -p $dir && cd $dir
cat << EOF > $dir/connect-standalone.properties
#************CREATING SNOWFLAKE Connector****************
bootstrap.servers=$BS

#************SNOWFLAKE VALUE CONVERSION****************
key.converter=org.apache.kafka.connect.storage.StringConverter
value.converter=com.snowflake.kafka.connector.records.SnowflakeJsonConverter
key.converter.schemas.enable=true
value.converter.schemas.enable=true
#************SNOWFLAKE ****************

offset.storage.file.filename=/tmp/connect.offsets
# Flush much faster than normal, which is useful for testing/debugging
offset.flush.interval.ms=10000

#*********** FOR SSL  ****************
security.protocol=SSL
ssl.truststore.location=/tmp/kafka.client.truststore.jks
ssl.truststore.password=changeit
ssl.enabled.protocols=TLSv1.1,TLSv1.2

consumer.security.protocol=SSL
consumer.ssl.truststore.location=/tmp/kafka.client.truststore.jks
consumer.ssl.truststore.password=changeit
consumer.ssl.enabled.protocols=TLSv1.1,TLSv1.2
EOF

A configuration file connect-standalone.properties is created in directory /home/ssm-user/snowpipe-streaming/scripts

8. Create a security client.properties configuration file for the producer

Run the following commands to create a security configuration file client.properties for the MSK cluster

dir=/home/ssm-user/snowpipe-streaming/scripts
cat << EOF > $dir/client.properties
security.protocol=SSL
ssl.truststore.location=/tmp/kafka.client.truststore.jks
ssl.truststore.password=changeit
ssl.enabled.protocols=TLSv1.1,TLSv1.2
EOF

A configuration file client.properties is created in directory /home/ssm-user/snowpipe-streaming/scripts

9. Create a streaming topic called "streaming" in the MSK cluster

Now we can run the following commands to create a Kafka topic on the MSK cluster to stream our data.

$HOME/snowpipe-streaming/kafka_2.12-2.8.1/bin/kafka-topics.sh --bootstrap-server $BS --command-config $HOME/snowpipe-streaming/scripts/client.properties --create --topic streaming --partitions 2 --replication-factor 2

You should see the response Created topic streaming if it is successful.

To describe the topic, run the following commands:

$HOME/snowpipe-streaming/kafka_2.12-2.8.1/bin/kafka-topics.sh --bootstrap-server $BS --command-config $HOME/snowpipe-streaming/scripts/client.properties --describe --topic streaming

You should see there are two partitions with a replication factor of 2 in the streaming topic. See below example screenshot:

1. Creating user, role, and database

First login to your Snowflake account as a power user with ACCOUNTADMIN role. Then run the following SQL commands in a worksheet to create a user, database and the role that we will use in the lab.

-- Set default value for multiple variables
-- For purpose of this workshop, it is recommended to use these defaults during the exercise to avoid errors
-- You should change them after the workshop
SET PWD = 'Test1234567';
SET USER = 'STREAMING_USER';
SET DB = 'MSK_STREAMING_DB';
SET WH = 'MSK_STREAMING_WH';
SET ROLE = 'MSK_STREAMING_RL';

USE ROLE ACCOUNTADMIN;

-- CREATE USERS
CREATE USER IF NOT EXISTS IDENTIFIER($USER) PASSWORD=$PWD  COMMENT='STREAMING USER';

-- CREATE ROLES
CREATE OR REPLACE ROLE IDENTIFIER($ROLE);

-- CREATE DATABASE AND WAREHOUSE
CREATE DATABASE IF NOT EXISTS IDENTIFIER($DB);
USE IDENTIFIER($DB);
CREATE OR REPLACE WAREHOUSE IDENTIFIER($WH) WITH WAREHOUSE_SIZE = 'SMALL';

-- GRANTS
GRANT CREATE WAREHOUSE ON ACCOUNT TO ROLE IDENTIFIER($ROLE);
GRANT ROLE IDENTIFIER($ROLE) TO USER IDENTIFIER($USER);
GRANT OWNERSHIP ON DATABASE IDENTIFIER($DB) TO ROLE IDENTIFIER($ROLE);
GRANT USAGE ON WAREHOUSE IDENTIFIER($WH) TO ROLE IDENTIFIER($ROLE);

-- SET DEFAULTS
ALTER USER IDENTIFIER($USER) SET DEFAULT_ROLE=$ROLE;
ALTER USER IDENTIFIER($USER) SET DEFAULT_WAREHOUSE=$WH;


-- RUN FOLLOWING COMMANDS TO FIND YOUR ACCOUNT IDENTIFIER, COPY IT DOWN FOR USE LATER
-- IT WILL BE SOMETHING LIKE <organization_name>-<account_name>
-- e.g. ykmxgak-wyb52636

WITH HOSTLIST AS
(SELECT * FROM TABLE(FLATTEN(INPUT => PARSE_JSON(SYSTEM$allowlist()))))
SELECT REPLACE(VALUE:host,'.snowflakecomputing.com','') AS ACCOUNT_IDENTIFIER
FROM HOSTLIST
WHERE VALUE:type = 'SNOWFLAKE_DEPLOYMENT_REGIONLESS';

Please write down the Account Identifier, we will need it later.

Next we need to configure the public key for the streaming user to access Snowflake programmatically.

First, in the Snowflake worksheet, replace < pubKey > with the content of the file /home/ssm-user/pub.Key (see step 4 by clicking on section #2 Create a provisioned Kafka cluster and a Linux jumphost in AWS in the left pane) in the following SQL command and execute.

use role accountadmin;
alter user streaming_user set rsa_public_key='< pubKey >';

See below example screenshot:

Now logout of Snowflake, sign back in as the default user streaming_user we just created with the associated password (default: Test1234567). Run the following SQL commands in a worksheet to create a schema (e.g. MSK_STREAMING_SCHEMA) in the default database (e.g. MSK_STREAMING_DB):

SET DB = 'MSK_STREAMING_DB';
SET SCHEMA = 'MSK_STREAMING_SCHEMA';

USE IDENTIFIER($DB);
CREATE OR REPLACE SCHEMA IDENTIFIER($SCHEMA);

2. Install SnowSQL (optional but highly recommended)

SnowSQL is the command line client for connecting to Snowflake to execute SQL queries and perform all DDL and DML operations, including loading data into and unloading data out of database tables.

To install SnowSQL. Execute the following commands on the Linux Session Manager console:

curl https://sfc-repo.snowflakecomputing.com/snowsql/bootstrap/1.2/linux_x86_64/snowsql-1.2.24-linux_x86_64.bash -o /tmp/snowsql-1.2.24-linux_x86_64.bash
echo -e "~/bin \n y" > /tmp/ans
bash /tmp/snowsql-1.2.24-linux_x86_64.bash < /tmp/ans

See below example screenshot:

Next set the environment variable for Snowflake Private Key Phrase:

export SNOWSQL_PRIVATE_KEY_PASSPHRASE=<key phrase you set up when running openssl previously>

Note that you should add the command above in the ~/.bashrc file to preserve this environment variable across sessions.

echo "export SNOWSQL_PRIVATE_KEY_PASSPHRASE=$SNOWSQL_PRIVATE_KEY_PASSPHRASE" >> ~/.bashrc

Now you can execute this command to interact with Snowflake:

$HOME/bin/snowsql -a <Snowflake Account Identifier> -u streaming_user --private-key-path $HOME/rsa_key.p8 -d msk_streaming_db -s msk_streaming_schema

See below example screenshot:

Type Ctrl-D to get out of SnowSQL session.

You can edit the ~/.snowsql/config file to set default parameters and eliminate the need to specify them every time you run snowsql.

At this point, the Snowflake setup is complete.

1. Run the following commands to collect various connection parameters for the Kafka connector

cd $HOME
outf=/tmp/params
cat << EOF > /tmp/get_params
a=''
until [ ! -z \$a ]
do
 read -p "Input Snowflake account identifier: e.g. ylmxgak-wyb53646 ==> " a
done

echo export clstr_url=\$a.snowflakecomputing.com > $outf
export clstr_url=\$a.snowflakecomputing.com

read -p "Snowflake cluster user name: default: streaming_user ==> " user
if [[ \$user == "" ]]
then
   user="streaming_user"
fi

echo export user=\$user >> $outf
export user=\$user

pass=''
until [ ! -z \$pass ]
do
  read -p "Private key passphrase ==> " pass
done

echo export key_pass=\$pass >> $outf
export key_pass=\$pass

read -p "Full path to your Snowflake private key file, default: /home/ssm-user/rsa_key.p8 ==> " p8
if [[ \$p8 == "" ]]
then
   p8="/home/ssm-user/rsa_key.p8"
fi

priv_key=\`cat \$p8 | grep -v PRIVATE | tr -d '\n'\`
echo export priv_key=\$priv_key  >> $outf
export priv_key=\$priv_key
cat $outf >> $HOME/.bashrc
EOF
. /tmp/get_params

See below example screen capture.

2. Run the following commands to create a Snowflake Kafka connect property configuration file:

dir=/home/ssm-user/snowpipe-streaming/scripts
cat << EOF > $dir/snowflakeconnectorMSK.properties
name=snowpipeStreaming
connector.class=com.snowflake.kafka.connector.SnowflakeSinkConnector
tasks.max=4
topics=streaming
snowflake.private.key.passphrase=$key_pass
snowflake.database.name=MSK_STREAMING_DB
snowflake.schema.name=MSK_STREAMING_SCHEMA
snowflake.topic2table.map=streaming:MSK_STREAMING_TBL
buffer.count.records=10000
buffer.flush.time=5
buffer.size.bytes=20000000
snowflake.url.name=$clstr_url
snowflake.user.name=$user
snowflake.private.key=$priv_key
snowflake.role.name=MSK_STREAMING_RL
snowflake.ingestion.method=snowpipe_streaming
value.converter.schemas.enable=false
jmx=true
key.converter=org.apache.kafka.connect.storage.StringConverter
value.converter=org.apache.kafka.connect.json.JsonConverter
errors.tolerance=all
EOF

Finally, we are ready to start ingesting data into the Snowflake table.

1. Start the Kafka Connector for Snowpipe streaming

Go back to the Linux console and execute the following commands to start the Kafka connector.

$HOME/snowpipe-streaming/kafka_2.12-2.8.1/bin/connect-standalone.sh $HOME/snowpipe-streaming/scripts/connect-standalone.properties $HOME/snowpipe-streaming/scripts/snowflakeconnectorMSK.properties

If everything goes well, you should something similar to screen capture below:

2. Start the producer that will ingest real-time data to the MSK cluster

Start a new Linux session in step 3 by clicking on section #2 Create a provisioned Kafka cluster and a Linux jumphost in AWS in the left pane.

curl --connect-timeout 5 http://ecs-alb-1504531980.us-west-2.elb.amazonaws.com:8502/opensky | $HOME/snowpipe-streaming/kafka_2.12-2.8.1/bin/kafka-console-producer.sh --broker-list $BS --producer.config $HOME/snowpipe-streaming/scripts/client.properties --topic streaming

You should see response similar to screen capture below if everything works well.

Note that in the script above, the producer queries a Rest API that provides real-time flight data over the San Francisco Bay Area in JSON format. The data includes information such as timestamps, icao numbers, flight IDs, destination airport, longitude, latitude, and altitude of the aircraft, etc. The data is ingested into the streaming topic on the MSK cluster and then picked up by the Snowpipe streaming Kafka connector, which delivers it directly into a Snowflake table msk_streaming_db.msk_streaming_schema.msk_streaming_tbl.

Now, switch back to the Snowflake console and make sure that you signed in as the default user streaming_user. The data should have been streamed into a table, ready for further processing.

1. Query the raw data

To verify that data has been streamed into Snowflake, execute the following SQL commands.

use msk_streaming_db;
use schema msk_streaming_schema;
show channels in table msk_streaming_tbl;

You should see that there are two channels, corresponding to the two partitions created earlier in the topic.

Now run the following query on the table.

select * from msk_streaming_tbl;

You should see there are two columns in the table: RECORD_METADATA and RECORD_CONTENT as shown in the screen capture below.

The RECORD_CONTENT column is an JSON array that needs to be flattened.

2. Flatten the raw JSON data

Now execute the following SQL commands to flatten the raw JSONs and create a materialized view with multiple columns based on the key names.

create or replace view flights_vw
  as select
    f.value:utc::timestamp_ntz ts_utc,
    CONVERT_TIMEZONE('UTC','America/Los_Angeles',ts_utc::timestamp_ntz) as ts_pt,
    f.value:alt::integer alt,
    f.value:dest::string dest,
    f.value:orig::string orig,
    f.value:id::string id,
    f.value:icao::string icao,
    f.value:lat::float lat,
    f.value:lon::float lon,
    st_geohash(to_geography(ST_MAKEPOINT(lon, lat)),12) geohash,
    year(ts_pt) yr,
    month(ts_pt) mo,
    day(ts_pt) dd,
    hour(ts_pt) hr
FROM   msk_streaming_tbl,
       Table(Flatten(msk_streaming_tbl.record_content)) f;

The SQL commands create a view, convert timestamps to different time zones, and use Snowflake's Geohash function to generate geohashes that can be used in time-series visualization tools like Grafana

Let's query the view flights_vw now.

select * from flights_vw;

As a result, you will see a nicely structured output with columns derived from the JSONs

3. Stream real-time flight data continuously to Snowflake

We can now write a loop to stream the flight data continuously into Snowflake.

Go back to the Linux session and run the following script.

while true
do
  curl --connect-timeout 5 -k http://ecs-alb-1504531980.us-west-2.elb.amazonaws.com:8502/opensky | $HOME/snowpipe-streaming/kafka_2.12-2.8.1/bin/kafka-console-producer.sh --broker-list $BS --producer.config $HOME/snowpipe-streaming/scripts/client.properties --topic streaming
  sleep 10
done

You can now go back to the Snowflake worksheet to run a select count(1) from flights_vw query every 10 seconds to verify that the row counts is indeed increasing.

So far we have been hosting the Kafka connector for Snowpipe Streaming on the EC2 instance. You can also use Amazon MSK Connect to manage the connector.

*Note that in order to use MSKC, it is suggested to run your MSK cluster in a private subnet with egress to the internet via the NAT gateway for it to work. See this AWS documentation for more information.

1. Create a S3 bucket to store the custom plugins

Follow this AWS documentation to create a S3 bucket.

2. Upload the libraries to the S3 bucket

On your EC2 session, run the following commands to compress the libraries into a zipped file.

cd $HOME/snowpipe-streaming/kafka_2.12-2.8.1/libs
zip -9 /tmp/snowpipeStreaming-mskc-plugins.zip *
aws s3 cp /tmp/snowpipeStreaming-mskc-plugins.zip s3://<your s3 bucket name>/snowpipeStreaming-mskc-plugins.zip

3. Create a custom plugin in MSK

Go to the MSK console, click Custom plugins on the left pane. Click Create Custom plugin.

Fill in the s3 path to your uploaded zip file, e.g. s3://my-mskc-bucket/snowpipeStreaming-mskc-plugins.zip Give the custom plugin a name, e.g. my-mskc-plugin, click Create custom plugin.

4. Create a connector

Click Connectors on the left pane, then click Create connector.

Check the Use existing custom plugin button. Select the custom plugin you just created, click Next.

Give the connector a name, e.g. snowpipeStreaming in the Basic information section.

Select the MSK cluster you want to associate this connector with. Scroll down to Configuration settings, copy and paste the content from the configuration file: $HOME/snowpipe-streaming/scripts/snowflakeconnectorMSK.properties in the EC2 instance.

Leave all other settings as default, further scroll down to Access permissions. In the Choose service role drop-down menu, select the role created by the Cloudformation template in the beginning of this quickstarts. The role name should look something like this -MSKConnectRole-. Click Next.

In the Security page, leave everything as default, click Next. Skip the Logs page as it is optional, click Next. Review the configurations and click Create connector. The connector will be created in about 5-10 minutes.

At this point, the Kafka connector for Snowpipestreaming has been configured, it is running and managed by MSKC, all you need to do is to run the source connector to ingest live data continuously as shown in Step 3 of Section 6.

Previously we ingested raw jsons into the table MSK_STREAMING_TBL and did a DDL to create a nicely formulated view with the column names mapped to the keys in the jsons. You can now skip the DDL step with schema detection enabled to detect the schema of the streaming data and load data into tables that automatically match any user-defined schema.

1. Modify the Snowpipe streaming properties file

Modify the two lines in $HOME/snowpipe-streaming/scripts/snowflakeconnectorMSK.properties

from

topics=streaming
snowflake.topic2table.map=streaming:MSK_STREAMING_TBL

to

topics=streaming,streaming-schematization
snowflake.topic2table.map=streaming:MSK_STREAMING_TBL,streaming-schematization:MSK_STREAMING_SCHEMATIZATION_TBL

#Also enable schematiaztion by adding
snowflake.enable.schematization=true

Save the properties file

2. Create a new topic in MSK

We now need to create a new topic streaming-schematization in MSK cluster by running the following command:

$HOME/snowpipe-streaming/kafka_2.12-2.8.1/bin/kafka-topics.sh --bootstrap-server $BS --command-config $HOME/snowpipe-streaming/scripts/client.properties --create --topic streaming-schematization --partitions 2 --replication-factor 2

3. Restart the consumer

Restart the consumer by issuing the following shell command in a new Session Manager console.

kill -9 `ps -ef | grep java | grep -v grep | awk '{print $2}'`
$HOME/snowpipe-streaming/kafka_2.12-2.8.1/bin/connect-standalone.sh $HOME/snowpipe-streaming/scripts/connect-standalone.properties $HOME/snowpipe-streaming/scripts/snowflakeconnectorMSK.properties

4. Ingest data

Now ingest some data into the newly created topic by running the following command in a new Session Manager console.

curl --connect-timeout 5 http://ecs-alb-1504531980.us-west-2.elb.amazonaws.com:8502/opensky | \
jq -c '.[]' | \
while read i ; \
do \
echo $i | \
$HOME/snowpipe-streaming/kafka_2.12-2.8.1/bin/kafka-console-producer.sh --broker-list $BS --producer.config $HOME/snowpipe-streaming/scripts/client.properties --topic streaming-schematization ; \
echo $i ; \
done

You should see the producer using jq to break up the json array and stream in the records one by one.

5. Verify schema detection is working

Now head over to the Snowflake UI, and issue the following SQL command:

select * from msk_streaming_schematization_tbl;

You should see the table already contains the keys in json records as column names with values populated. There is no need to do DDL as before.

Note that using the shell script connect-standalone.sh that comes with the Kafka distribution is not the most efficient way of ingesting data into Snowflake as it opens and closes the topic every single time it calls the Snowpipe streaming SDK as you can see in the script in Step 4 above. We are doing this for the purpose of a quick demonstration.

Other programing languages like Python or Java are highly recommended as they keep the topic open throughout the ingesting process.

When you are done with the demo, to tear down the AWS resources, simply go to the Cloudformation console. Select the Cloudformation template you used to deploy the MSK cluster at the start of the demo, then click the Delete tab. All the resources that were deployed previously, such as EC2 instances, MSK clusters, roles, etc., will be cleaned up.

See example screen capture below.

After the deletion of the MSK cluster, you will also need to delete the Cloudformation template for VPC if you created your own at the very beginning of the lab.

For Snowflake cleanup, execute the following SQL commands.

USE ROLE ACCOUNTADMIN;

DROP DATABASE MSK_STREAMING_DB;
DROP WAREHOUSE MSK_STREAMING_WH;
DROP ROLE MSK_STREAMING_RL;

-- Drop the streaming user
DROP USER IF EXISTS STREAMING_USER;

In this lab, we built a demo to show how to ingest time-series data using Snowpipe streaming and Kafka with low latency. We demonstrated this using a self-managed Kafka connector on an EC2 instance. However, for a production environment, we recommend using Amazon MSK Connect, which offers scalability and resilience through the AWS infrastructure. Alternatively, if you have infrastructure supported by either Amazon EKS or Amazon ECS, you can use them to host your containerized Kafka connectors as well.

For those of you who are interested in learning more about how to build sleek dashboards for monitoring the live flight data, please navigate to this quickstart to continue.

Related Resources
